Asus ESC4000-E11 Server
Scalable High-Performance GPU Server
Overview of Asus ESC4000-E11
As ASUS server partners, we are excited to introduce the ESC4000-E11, a high-performance 2U GPU server meticulously designed for handling AI workloads, deep learning, high-performance computing (HPC), cloud computing, and big data analytics. Powered by the latest 4th and 5th Generation Intel Xeon Scalable processors, this server offers exceptional computing power, scalability, and energy efficiency, making it an ideal choice for modern AI-driven enterprises and data centers.
The ESC4000-E11 supports DDR5 memory, PCIe Gen5 expansion slots, and high-speed NVMe storage, ensuring optimal performance and the capability to manage large-scale data efficiently. Additionally, its remote management features facilitate seamless monitoring and administration, making it a perfect solution for enterprise IT infrastructure and mission-critical AI applications.
Features and Server specs of Asus ESC4000-E11
The ASUS ESC4000-E11 server is engineered for high-performance dual-socket processing and is compatible with both 4th and 5th Generation Intel Xeon Scalable processors. This feature guarantees exceptional computing efficiency, making it particularly advantageous for AI and high-performance computing (HPC) tasks. The server can also support up to 4 dual-slot NVIDIA GPUs, which facilitates powerful AI acceleration necessary for machine learning and deep learning applications.
Regarding connectivity, the server incorporates PCI Express® (PCIe®) 5.0 technology, which provides an outstanding bandwidth of 32 GT/s, effectively doubling the capacity of PCIe 4.0 while also reducing power consumption and enhancing scalability for future requirements. For cooling, it is expertly designed with advanced thermal management solutions that include both air-cooled and liquid-cooled options, thereby enhancing overall efficiency.
As an authorized ASUS partner, we specialize in offering the latest AI-powered PCs and laptops, including premium models like the ProArt, ZenBook, and ROG series. These high-performance AI PCs are designed for creators, gamers, and professionals, featuring powerful NVIDIA and AMD processors that deliver exceptional speed, efficiency, and AI-driven capabilities.
Whether you need a high-end AI PC for content creation, an ultra-slim ZenBook for productivity, or a gaming powerhouse from the ROG lineup, we have the right solution for you.
Contact us today to learn more or click the link below to explore our range of ASUS AI PCs and laptops!
Processor: Supports 2 x Socket E (LGA 4677) for 4th and 5th Generation Intel Xeon Scalable Processors.
Memory: Features 32 DIMM slots (16 per CPU) with an 8-channel memory architecture per CPU, capable of supporting up to 8TB DDR5 memory (including Crow Pass technology).
Expansion Slots: Includes 6 PCIe slots, comprising up to 4 x PCIe Gen5 x16 for GPUs, 1 x OCP 3.0 slot, and 1 x PCIe Gen5 x16 slot for networking/storage expansion.
Storage Bays: Supports 8 x 2.5” or 3.5” hot-swap drive bays, accommodating NVMe, SAS, and SATA options, along with 2 x M.2 slots (SATA/PCIe, up to 22110 form factor).
Networking: Offers options for 1 x Quad-Port Intel I350-AM4 1G LAN or 1 x Dual-Port Intel X710-AT2 10G LAN, with optional 100GbE high-speed connectivity.
Graphics: Integrated Aspeed AST2600 BMC controller with 64MB VRAM for remote management and visualization.
Front I/O Ports: Includes 2 x USB 3.2 Gen1 ports and 1 x VGA port for easy access.
Rear I/O Ports: Features 2 x USB 3.2 Gen1 ports, 1 x VGA port, 1 x RJ-45 management LAN port, and optional high-speed network connectivity.
OS Support: Compatible with Windows Server 2019/2022, RedHat Enterprise Linux, SuSE Linux Enterprise Server, CentOS, Ubuntu, and VMware, with the latest support available on the ASUS website.
Management: Equipped with ASUS Control Center (Classic) for in-band management and ASMB11-iKVM for KVM-over-IP remote access.
Physical Dimensions: Measures 800mm x 448mm x 175mm (2U) or 31.5″ x 17.6″ x 6.9″, making it suitable for high-density rack deployments.
Weight: The gross weight, including packaging, is 42 kg, ensuring a durable and robust build.
Power Supply: Supports 1+1 redundant 2200W 80 PLUS Titanium power supplies, providing high efficiency and reliability.
Operating Environment: Operates within 10°C to 35°C, with a non-operational range of -40°C to 60°C and a humidity tolerance of 20% to 90% (non-condensing).
